TG Kapton Insulation Sheet Black Edition

TG Kapton Insulation Sheet

Kapton Insulation Sheet is an assembly aid for electrically conductive thermal interface material (TIM). It is ideal for masking components such as SMDs on a CPU or GPU if they are to be used with Conductonaut liquid metal, Carbonaut or KryoSheet.

$10.41

Content: 1444 mm² ($0.72 / 100 mm²)

Prices incl. VAT plus shipping costs

Color

Yellow

Black

Menge

50 pcs.

EAN: 4260711992223

MPN: TG-KIS-B-10-60-50

Product information "TG Kapton Insulation Sheet Black Edition"

The Kapton Insulation Sheet Black Edition is a polyimide film that can be used at high temperatures up to 260 °C and serves as an installation aid for electrically conductive thermal interface materials (TIM), such as Conductonaut liquid metal, Carbonaut, or KryoSheet.

Black Edition: Thinner, stronger, and ideal for precise masking

It is ideal for masking components such as SMDs on a CPU or GPU when using these materials. Compared to the standard Kapton Insulation Sheet, the Black Edition is slightly thinner (30 µm instead of 40 µm) and offers a significantly higher breakdown voltage of 5 kV. The Kapton Insulation Sheet Black Edition is supplied as 10 carrier sheets, each containing 5 Kapton adhesive strips. Each strip measures 10 mm in width and 60 mm in length, with a thickness of 30 µm. It is recommended to thoroughly clean the contact surfaces before applying the insulation sheet (e.g., using isopropyl alcohol).

properties

50 adhesive strips 10×60 mm
Thickness of 30 µm
Electrically insulating
Max temperature: 260 °C
Breakdown voltage: over 5 kV
Clean the adhesive surface beforehand!

Scope of delivery

10x carrier foil with 5 Kapton Insulation Sheets each

Note on use with High Performance Heatspreaders and Direct-Die coolers

The TG Kapton Insulation Sheet should not be used in combination with High Performance Heatspreaders or Direct-Die coolers. Instead, a thin layer of TG Shield should be applied to protect the electronic components. The reason for this is that High Performance Heatspreaders (HPHS) and Direct-Die coolers rest directly on the CPU package. When a Kapton Insulation Sheet is used, the internal structure of the HPHS or Direct-Die cooler may rest on the Insulation Sheet, preventing contact between the CPU die and the HPHS or cooler.

Kapton Insulation Sheets comparison

Properties	Kapton Insulation Sheet	Kapton Insulation Sheet Black Edition
Material	Polyimid (PI)	Polyimid (PI)
Color	Yellow	Black, matte
Total thickness	40 µm	30 µm
Long-term temperature resistance	180 °C	180 °C
Short-term temperature resistance	280 °C	260 °C
Breakdown Voltage	Over 1 kV	5 kV
Electrically insulating	Yes	Yes
