KryoSheet

The KryoSheet Graphene Thermal Pads are an excellent alternative to thermal pastes and have an adaptable surface with very high thermal conductivity. Compared to Carbonaut pads, KryoSheet offers significantly higher thermal conductivity.

$23.28

Content: 625 mm² ($3.72 / 100 mm²)

Prices incl. VAT plus shipping costs

Size
Thickness
EAN: 4260711990816
MPN: TG-KS-25-25

Product information "KryoSheet"

The graphene thermal pads of the Thermal Grizzly KryoSheet series can be used excellently as an alternative to thermal pastes from the upper performance segment. Similar to the Carbonaut pads, they have an adaptable surface with very high thermal conductivity. Compared to Carbonaut pads, KryoSheet offers significantly higher thermal conductivity as a high-end product. This increased thermal conductivity is not only due to the choice of material, but also due to the innovative manufacturing process. KryoSheet does not contain any liquid components and is therefore not subject to ordinary aging as is the case with traditional thermal paste. Drying out is not possible.

Properties

  • Outstanding thermal conductivity
  • Easy to use
  • Consistently high performance
  • Extreme durability
  • Attention: Electrically conductive! Follow the instructions!
Radar Chart KryoSheet
Application example KryoSheet

Outstanding and consistent thermal conductivity

The KryoSheet graphene pads have a molecular structure stacked in the Z-direction. This optimized structure allows for outstanding and consistent thermal conductivity. This is due to a specially developed manufacturing process in which the hexagonal crystal structure of the graphite is broken up along the basal plane in order to be able to exploit the anisotropy of the thermal conductivity of the graphite. As a side effect of this complex manufacturing process, however, the electrical conductivity is also increased and the stability of the KryoSheet pads is influenced, so that the pads can only be used according to instructions!

long_term_TG
Extreme durability
thermal_conductivity_TG
Outstanding thermal conductivity
long_term_durability_TG
Consistently high performance
electrically_conductive_TG
Attention: Electrically conductive!

Product information "KryoSheet"

The graphene thermal pads of the Thermal Grizzly KryoSheet series can be used excellently as an alternative to thermal pastes from the upper performance segment. Similar to the Carbonaut pads, they have an adaptable surface with very high thermal conductivity. Compared to Carbonaut pads, KryoSheet offers significantly higher thermal conductivity as a high-end product. This increased thermal conductivity is not only due to the choice of material, but also due to the innovative manufacturing process. KryoSheet does not contain any liquid components and is therefore not subject to ordinary aging as is the case with traditional thermal paste. Drying out is not possible.

Radar Chart KryoSheet

Properties

  • Outstanding thermal conductivity
  • Easy to use
  • Consistently high performance
  • Extreme durability
  • Attention: Electrically conductive! Follow the instructions!
Application example KryoSheet

Outstanding and consistent thermal conductivity

Z-direction. This optimized structure allows for outstanding and consistent thermal conductivity. This is due to a specially developed manufacturing process in which the hexagonal crystal structure of the graphite is broken up along the basal plane in order to be able to exploit the anisotropy of the thermal conductivity of the graphite. As a side effect of this complex manufacturing process, however, the electrical conductivity is also increased and the stability of the KryoSheet pads is influenced, so that the pads can only be used according to instructions!

long_term_TG
Extreme durability
thermal_conductivity_TG
Outstanding thermal conductivity
long_term_durability_TG
Consistently high performance
electrically_conductive_TG
Attention: Electrically conductive!

KryoSheet is available in multiple sizes

The KryoSheet  25x25 mm is compatible with:

Nvidia GPUs:

  • RTX 5070
  • RTX 4080
  • RTX 4070 | RTX 4070 ti
  • RTX 4060 | RTX 4060 ti
  • RTX 3070 | RTX 3070 ti
  • RTX 3060 | RTX 3060 ti
  • RTX 3050
  • RTX 2070
  • RTX 2060 | RTX 2060 Super
  • GTX 1080 | GTX 1080 ti
  • GTX 1070 | GTX 1070 ti
  • GTX 1060
  • GTX 1050 | GTX 1050 ti
  • GTX 1660 | GTX 1660 Super | GTX 1660 ti
  • GTX 1650 | GTX 1650 Super
  • GTX 1630
  • Titan X

AMD GPUs:

  • RX 9060 | RX 9060 XT
  • RX 7600
  • RX 6750 XT
  • RX 6700 | RX 6700 XT
  • RX 6650 XT
  • RX 6600 | RX 6600 XT
Various sizes

Note:

Multiple use of KryoSheet is not recommended!

When disassembling the cooler and handling the KryoSheet after use, micro-cracks may occur in the structure of the graphene pads, which can affect performance.


Color: anthracite
Electrically insulating: No
Operating temperature: -250°C to +150°C
Size: 25 x 25 mm
Thickness: 0.2 mm
